GOODS LIFTS
Goods Lifts
Goods Lifts, also known as Cage Hoists or Freight Elevators, are lifting machines used to safely transport heavy materials between floors in factories, warehouses, and industrial units, these are made specifically to carry goods and equipment, not people.
At Cranoist Engineers, we design and manufacture strong, secure, and customizable goods lifts that meet the demands of industries like chemicals, pharmaceuticals, and manufacturing.
Capacity & Size Range
• Capacity: 0.5 Ton Up to 10 Ton
• Cage Size:
Up to 4 meters wide x 4 meters deep
• Lift
Height: Can be designed to suit your building’s
floor levels
Types of Goods Lifts We Offer
1. Hoist-Type Lifts: Ideal where shaft space is
smaller than the required cabin size. No
counterweight needed.
2. Hydraulic Lifts:
Smooth and powerful lifting for moderate height
ranges.
3. Scissor Lifts: Suitable for
ground-to-platform level transfer.
4.
Counterweight Lifts: Available on request for large,
balanced load applications.
Power & Installation Requirements
• Power Supply: 415V, 3-phase, 50Hz AC
• Pit
Depth: Approx. 1000mm (varies by lift type)
•
Headroom: Minimum 3200mm needed
• Control
Logic: Operated from any floor, with auto-stop when
reaching the target floor
Key Features of Our Goods Lifts
• Safe & Sturdy Design: MS-fabricated cage
cabins guided by solid ‘T’ rails ensure smooth and
steady movement.
• No Counterweight
Required: Saves space and allows for larger cabin
size.
• Electro-Mechanical Safety: The lift
won’t move unless all doors are securely locked.
•
Custom Entry Options: Choose from same-side,
opposite-side, or L-type entry/exit directions.
•
Push Button Operation: Control panel on each floor
for easy calling and sending of the lift.
•
Automatic Door Locking System: Prevents movement if
any landing door is open.
• Optional Flameproof
Setup: For use in hazardous areas such as chemical
or pharma zones.
• GMP-Grade Stainless Steel
Options: Available for cleanroom or explosive
environments (Gas Group I, IIA, IIC)
